Dimensions
Diameter under rollers 65 mm
Outside diameter 110 mm
Width 27 mm

Product net weight 0.88 kg

Basic dynamic load rating 127 kN
Basic static load rating 112 kN
Reference speed 6 700 r/min
Limiting speed 8 000 r/min
SKF performance classSKF Explorer


Fw
65 mm Diameter under rollers
D
110 mm Outside diameter
C
27 mm Width
D1
≈91.4 mm Shoulder diameter outer ring
r1,2
min.2 mm Corner radius

---
