Product details
Brand FAG Bearings

Material Steel Cage

Item Dimensions LxWxH 1.77 x 0.98 x 3.94 inches
Item Weight 0.86 Kilograms
Specification Met Din Iso 281, En 10139, Din 620-4, Din 623-1, Iso 683-17, Din 625-1, Iso 286, Sae J403, Iso 281
Bearing Type Ball Bearing
Deep groove geometry for high speeds and supporting both radial and axial loads
“Medium” bearing design for average to above average radial loads and light to average axial loads
C3 radial clearance allows thermal expansion for continuous operating temperatures up to 120 degrees C/248 degrees F
Sheet steel cage evenly spaces balls for reduced friction, vibration, and noise
Rubber seals on both sides of the bearing keep the lubricant in and contaminants out
Specifications for this item
Bearing Type Ball Bearing
Bore Diameter 45 millimeters
Brand Name FAG Bearings
Compatible Lubricant Type Grease
Dynamic Load Capacity 7100 pounds

Inside Diameter 45 millimeters
Item Diameter 100 millimeters
Item Weight 1.90 pounds
Material Steel Cage
Maximum Rotational Speed 4500 rpm
Measurement System Metric
Model Number 6309-2RSRC3
Number of Items 1
Part Number 6309-2RSR-L038-C3
Specification Met Din 620-4 , Din 623-1 , Iso 281 , Din 625-1 , Iso 286 , Iso 683-17 , Din Iso 281 , En 10139 , Sae J403
Static Load Capacity 1200 pounds

, Single Row, Double Sealed, Steel Cage, C3 Clearance, Metric, 45mm ID, 100mm OD, 25mm Width, 4500 rpm Maximum Rotational Speed, 7100 lbf Static Load Capacity, 1200 lbf Dynamic Load Capacity

---
