Dimensions
Bore diameter1.9685 in
Outside diameter3.5433 in
Width0.9055 in

Product net weight0.597 kg
Bore diameter50 mm
Outside diameter90 mm
Width23 mm

Basic dynamic load rating90 kN
Basic static load rating88 kN
Reference speed8 500 r/min
Limiting speed9 000 r/min
SKF performance classSKF Explorer


Bearing partComplete bearing
Axial displacement capabilityIn one direction
Number of rows1
Locating feature, bearing outer ringNone
Bore typeCylindrical
CageSheet metal
Number of flanges, outer ring2
Number of flanges, inner ring1
Loose flangeNone
Radial internal clearanceCN
Tolerance classNormal
CoatingWithout
SealingWithout
LubricantNone
Relubrication featureWithout
Indicative product carbon footprint to manufacture2.15 kg CO2e



Basic dynamic load rating20 233 lbf
Basic static load rating19 783 lbf
Reference speed8 500 r/min
Limiting speed9 000 r/min
SKF performance classSKF Explorer

---
