Bore diameter 200 mm
Outside diameter 360 mm
Width 58 mm
Product net weight 26.1 kg

Basic dynamic load rating 880 kN
Basic static load rating 1 060 kN
Reference speed 1 900 r/min
Limiting speed 3 200 r/min

SKF performance classSKF Explorer

d	200 mm	Bore diameter
D	360 mm	Outside diameter
B	58 mm	Width
d1	≈258 mm	Shoulder diameter of inner ring
D1	≈311.5 mm	Shoulder diameter of outer ring
F	243 mm	Raceway diameter of inner ring
r1,2	min.4 mm	Chamfer dimension
r3,4	min.4 mm	Chamfer dimension
s	max.2.6 mm	Permissible axial displacement

---
