Dimensions
Bore diameter 50 mm
Outside diameter 90 mm
Width 23 mm
Product net weight 0.563 kg

Basic dynamic load rating 90 kN
Basic static load rating 88 kN
Reference speed 8 500 r/min
Limiting speed 9 000 r/min
SKF performance classSKF Explorer

Dimensions
d
50 mm Bore diameter
D
90 mm Outside diameter
B
23 mm Width
D1
≈77.58 mm Shoulder diameter of outer ring
F
59.5 mm Raceway diameter of inner ring
r1,2
min.1.1 mm Chamfer dimension
r3,4
min.1.1 mm Chamfer dimension
s
max.1.5 mm Permissible axial displacement

---
