Dimensions
Bore diameter 40 mm
Outside diameter 68 mm
Width 15 mm
Product net weight 0.201 kg


Basic dynamic load rating 25.1 kN
Basic static load rating 26 kN
Reference speed 12 000 r/min
Limiting speed 22 000 r/min


d
40 mm Bore diameter
D
68 mm Outside diameter
B
15 mm Width
D1
≈57.6 mm Shoulder diameter outer ring
F
47 mm Raceway diameter inner ring
s
max.2.4 mm Permissible axial displacement from the normal position of one bearing ring relative to the other
r1,2
min.1 mm Chamfer dimension
r3,4
min.0.6 mm Chamfer dimension

---
